Cranemaster CM1-25T-1000: Passive Heave Compensator
Unique Group in partnership with Cranemaster offers the CM1-25T-1000 unit which is a state-of-the-art unit that protects crane, rigging and payload from shock loads, motion and/or excessive forces.It is manufactured in Norway and Germany using high quality materials and components.
Features
Rugged unit designed to operate in the harshest environments.
Adjustable spring and dampening characteristics.
Self-contained – no external connections of hoses or wire required.
Designed to reduce impacts in offshore lifts above sea level, through the splash zone and subsea.
Specifications
Safe Working Load (SWL): 25T.
Stroke length: 1000 mm.
Indicative load range: 1T – 20T.
Weight in air w/shackles: 260 kg.
CMAC control system: None.
Applications
Shock absorption air/subsea.
Overload protection air/subsea.
Pile run protection and tension control air/subsea.
Retrieval, decommissioning air/subsea.
Splash zone crossing.
-
